Hello dear readers!

This post is for anyone who wants to learn a little about the way we here at Special Collections and University Archives digitize our analog materials for online use and the platform where some of these can be accessed. The IAWA digital library platform (a selection of IAWA collections) gathers images that have been systematically digitized and described by University Libraries’ staff over the last decade. I was motivated to write this post now partly because new content is available on the platform and, while this is an opportunity to highlight these collections, I also want it to serve as a reminder that the platform is a growing, actively-maintained resource. But, as is the case with any resource, it may occasionally require some user guidance. First, here are a few of those newly available collections to explore:

Second, and one of the many caveats I’ll give in this post, is that the “user’s guide” of the title may be slightly misleading. I will not be providing a step-by-step tutorial or walkthrough of the platform, but will be setting out some loosely organized tips, thoughts on digitization, and some limitations for the curious researcher to be aware of.

How use? Some tips on information foraging

Because I’m an archivist obsessed with context (and I’m familiar with the site’s limitations), I will generally recommend browsing over searching. On the home page of the platform there is a prominent search bar, and just beneath that there are two icons: one for browsing by collection and one for browsing by item. A lack of context can make browsing by item somewhat confusing for the layperson or casual researcher, while drilling down through a single collection can be a good way to get your feet under you while you explore. What makes search hit-or-miss is that there are inevitably inconsistencies in metadata (depending on who created it) both in the way subject terms are applied and overall completeness (more on that below); occasionally, something simple that was missed in quality control, like a misspelling, can mean that an item fitting a user’s search criteria will not appear in their search results. Moreover, users will typically use queries that mirror natural or casual language use rather than formal subject headings or tags.

I will also note that the terms “collection” and “item” are used in an unintuitive way on the platform, which may reflect my own bias as someone who’s familiar with the physical arrangement of the manuscript collections represented on the site. From an archival perspective, “collection” is more intuitive because it corresponds with and is grouped under the creator (this is how archival records are organized, according to the principle of provenance), whereas an “item” on the platform refers to a grouping of physical objects (a real world folder, for example). Whereas in the real world environment I would consider an item to refer to a single drawing, sheet of paper, etc., an item on the platform is an aggregation that may represent anywhere between one object and two hundred (technically, there is no upper limit). The images below show what it looks like to move from the collection-level page to selecting and viewing an item.

Screenshot 1: Collection level view, Elsa Leviseur
Screenshot 2: Browsing items in collection, Elsa Leviseur
Screenshot 3: Selected item, image viewer and carousel

These images are meant to show what it looks like to browse and click through the platform. Here I’m using the Elsa Leviseur collection to show how one might navigate in a top-down manner (from collection down to item). The collection page (screenshot 1) contains identifying information, like the manuscript number, and a biographical sketch of its creator. Scrolling down the page reveals the “items” in the collection (screenshot 2 above). As noted above, these items refer to aggregations of varying size (usually corresponding to physical folders). Screenshot 3 then shows what it looks like to select one of these items. The image viewer is populated with the first image in the “item,” here a greeting card, which can be manipulated using the zoom and reset functions in the bottom righthand corner. Below the image itself is a carousel showing thumbnails of the other objects in the item (in this case the entire item is comprised of 21 images). On the righthand side of the page there’s a title and item-level description, which serves as a good illustration of metadata limitations for collection-scaled digitization and search functionality. Metadata, often used interchangeably with “description” in archives, cannot be done at the level of individual objects because there is too much material, and description is therefore mostly done at the aggregate level. The problem here is a lack of granularity that doesn’t allow the user to search with specificity. The image in Screenshot 3 is obviously a collaged greeting card, a piece of information nowhere listed in the metadata. Other information visually available (but not searchable) is the text in the image itself. Although it may not be immediately apparent to a casual user, “Fleischmann” was Elsa Leviseur’s married name, and it can be easily inferred that this is a family greeting card with pictures of her children. From this small example, one can easily imagine how much subject matter expertise and time it would take to give a full account of every object in every collection. Because every image is just one among many, the goal is to give objects a title that accurately (and briefly) describes varied content so that a given user can make educated guesses and inferences. In other words, some precision is sacrificed to accommodate more content. The researcher still needs to use their judgment when finding and interpreting these materials, and actively engage in the discovery process.

My recommendation to browse by collection notwithstanding, there is an obvious benefit to browsing the platform’s content at the item-level: it allows you to look at examples of the same kind of content across collections. There are a number of filters that can be applied to return a subset of items. For example, if you expand the options under “Medium” on the lefthand navigation menu, you can isolate the items tagged with “charcoal” or “photographic prints.” The gallery of images below are screenshots showing the ways these facets can be selected (note: filters will not automatically deselect when you apply a new one so you will have to manually toggle filters on and off as you go). While imperfect, these filters go some way toward allowing users to remix and reuse materials in ways that would be onerous, if not impossible, in a physical reading room.

Browsing with filter active (Medium: Charcoal)
Browsing with filter active (Medium: Photographic Print – Black and White)
Browsing with filter active (Tag: Associations and Committees)

There are other ways to use the platform, of course. We cannot possibly anticipate every type of use, but my hope is that this primer will answer a few questions about why things are organized the way they are and why some metadata tends toward vagueness rather than specificity. My final caveat for this section is that the digital library platform, while a useful tool, is not the place to search across all IAWA collections (see below).

The broader context of digitized content

At the beginning of this post, I emphasized the word “selection” because the digital library platform is not a comprehensive or complete representation of the IAWA, but in fact a rather small subset of incompletely digitized collections that vary dramatically in size and content. All this is to say that there’s often a misconception that archives can and should “put everything online.” Most archives simply don’t have the institutional capacity, meaning staffing, to support this work at scale. In the case of the digital library platform, the IAWA instance (there is a general instance for University Libraries and an IAWA-specific instance, which we’re discussing here) has largely been seeded by work on a CLIR (Council on Library and Information Resources) “digitizing hidden collections” grant-funded project that lasted from 2017 to 2019. During this period, several team members were hired (myself included) who were entirely dedicated to this project, which included image capture (scanning), metadata creation, and macro-level project management.

Understandably, there’s some user confusion that tends to happen around online representation of analog content. I sometimes field questions from patrons who mistakenly believe that when they search the digital library platform, where a subset of images live, they are searching across all IAWA collections. Typically archival institutions provide access to their materials in multiple ways, but the primary method is by describing collections in “finding aids,” a term of art meaning a resource that contains contextual and structural information about a collection. The context generally consists of biography, provenance, and descriptions of the scope and content of a collection; the structural information usually consists of a box/folder inventory where folder titles are indexed to a particular container (a box, for example). “Finding aid” usually refers to one of these specific inventories (I call it a “table of contents” for primary source material), but it can also refer to a more general guide like the one linked here: https://guides.lib.vt.edu/iawa/collections. This list of collections (ordered alphabetically by creator name) is probably where I would point someone starting their research; another place I would point them is the platform ARVAS (Archival Resources of the Virginias), an aggregator that can be used to search for and across finding aids. There are many ways to find and learn about our collections, even if at first glance it’s frustrating that information lives on different platforms that don’t talk to each other.

Even when we’re just talking about IAWA materials, let alone ALL Special Collections and University Archives materials, what’s available on the library platform is a fraction of a fraction of what is digitized, which in turn represents a fraction of all analog IAWA collections (not to mention born-digital records). Digitization in the context of everyday archival work is mostly done in a piecemeal ad hoc manner according to patrons’ requests. Some of these patrons are architectural historians, while some are homeowners interested in original drawings for their home, and others are family members who want to feel a sense of connection with the work of their grandmothers, mothers, aunts, or sisters. The question of how this case-by-case workflow differs from the one for ingesting collections into a platform is often the difference in the amount of context needed by a specific (and interested) researcher and a general audience coming to collections with no frame of reference. More specifically, what I mean is that it takes time to create quality metadata that supports understanding, reuse, and physical collocation for general users that remains useful long into the future. It’s not so much that creating metadata is not a good use of time, but since it could go on infinitely, it’s a question of priorities and resource allocation. For this reason, the amount of programmatic (systematic as opposed to ad hoc) digitization that takes place in archives varies from institution to institution. Even so, I tend to view digital reproductions as just another discovery pathway for the archives. They cannot (and should not) “replace” the original objects nor will they be sufficient for some forms of research, especially in design pedagogy where the full visual impact and materiality of the original object can be critical.

Thanks for reading!





Jade Snelling Architecture, International Archive of Women in Architecture (IAWA)

The Unrealized Vision of Architect Merle Easton’s “School Street Concept:” A Window Into Public Education Reform in 1970s West Philadelphia

The Merle Easton Collection is fully processed and the finding aid is available here.

Born in 1940, Merle Easton grew up in Sitka, Alaska, a port town on Baranof Island, southwest of Juneau, just to the west of British Columbia. She attended several schools in the Pacific Northwest before ultimately earning her Bachelor of Architecture from the University of Washington in Seattle in 1966. Interested in patterns of urban development and accounting for community needs in design, she developed a plan for a Community Center in central Seattle for her thesis project.

Following graduation, Easton found steady work in the Mid-Atlantic states. She worked independently, but also with agencies focused on concerns around urban renewal, affordable housing, and community displacement. As an independent architect, Easton developed the “street school” concept that was an outgrowth of the Mantua-Powelton Mini-School (MPMS) in West Philadelphia. Her conceptual design was intended to become a template for decentralized, modular schools, using inexpensive prefabricated units, integrated into their local neighborhoods. While the mini-school itself wasn’t a product of Easton’s design, it was her direct inspiration. An urban renewal project focused on refurbishing an abandoned factory building to house a small, integrated, and community-controlled school, the Mini-school sought to implement a radically different curriculum in a “found” space. The school served roughly 120-150 students (nearly all Black) in the two years it was open, all drawn from the surrounding area, and was meant to be a bridge between the middle class Powelton neighborhood and the predominantly Black and underserved Mantua neighborhood.

Riffing on the underlying philosophy of the Mini-school, Easton collaborated with neighborhood activist and MPMS principal Forrest Adams to develop a design geared toward scaling the existing school into a “mini-school system.” This prototype would offer affordable and sustainable growth that would expand the school without disrupting community life – it would rehabilitate and reuse space and resources, minimize waste and impingement, and weave community life and experiential learning into the fabric of elementary education. Easton developed drawings, scale models, and a film to promote the concept and get critical buy-in from the Mantua and Powelton communities and various funding agencies.

The project was written about in two issues of Progressive Architecture, Design and Planning: The New Schools by James Morisseau, and in Women in American Architecture: A Historic and Contemporary Perspective, edited by Susana Torre. In Torre’s book, Easton’s vision is described as “designed to cut time and expense in school construction, to revitalize high density inner city neighborhoods and to provide a more complete and relevant education including the entire community in the process. The school utilizes ‘found’ spaces, such as streets and empty lots. Prefabricated classrooms and toilets, multimedia domed meeting rooms and retractable barrel vaults plug into a community and draw upon people, existing businesses, and institutions as educational resources” (Torre 164). Adams and Easton both advocated for the idea of a “street school” as more cost effective than the traditional alternatives, arguing it would cost $7-10 per square foot compared to $21-30 per square foot of conventional school construction (Progressive Architecture 34). And yet the idea failed to garner enough critical traction to be fully realized.

The Mantua-Powelton Mini-School foundered for a few reasons, some rooted in a lack of critical oversight, others located in the novelty of its power structure. In Seven Schools, a 1972 publication from The Young Great Society Building Foundation, the authors cite the fact that the school had too little time to fully develop multiple radical approaches to education. This, coupled with not making good on its promise of engaging the community, lack of continued funding, and disagreements among its teachers regarding both curriculum and discipline, made for chaotic implementation and practically doomed the school from the start (Goldfarb et al. 33-35). On top of these problems there was the additional stressor of the refurbished factory being poorly adapted as an educational environment.

The mission of the school and, later, the “school street concept” was and continued to be community empowerment, but as Mark R. Shedd, superintendent of the School District of Philadelphia from 1967 to 1972, admitted in a private interview: “In the early days I thought community control was the thing. Now I think shared power is more realistic. I don’t think the central administration or the board or the superintendent can abdicate. I don’t think that’s proper or realistic. The mini-school represented, in part, an abdication of our responsibilities. We didn’t insist from the outset on the proper kind of management controls… We should have insisted upon a much closer audit and monitoring function. But we didn’t” (Shedd as qtd. on 35). Here there are multiple interlocking structures at play: the educational system itself, local power structures, community participation incentives (needed to generate buy-in), zoning (and redlining), resource allocation, and so on. While the mini-school and Easton’s “school street concept” were distinct from each other, I think it’s an interesting exercise to map the lessons of the mini-school onto the larger vision of the “street school.” That’s not to say that the school street or mini-school system would necessarily have failed in its implementation, but the exercise aims to understand how fraught it can be to navigate multiple entrenched systems while trying to generate innovative design solutions.

After her work on the mini-school Easton went on to work as a draftsperson, job captain, and staff architect at several firms and on a variety of projects, including hospitals, churches, and schools. As job captain at Victor H. Wilburn & Associates, she produced a report, included in her collection, analyzing the programs of the Wilmington Housing Authority and proposing measures and policy adjustments to make their programs more effective. In the introduction to the WHA report she summarizes the problem with Wilmington planning: “policy sprawl.” Quoting an interviewee: “‘Policy sprawl’ – that ungraceful, bits-and-pieces spread of plans and projects without any overall vision to offer the public” (representative of Gauge Corporation quoted in WHA Report). A consistent thread running through Easton’s materials is her commitment to “big picture” thinking about long-term development and planning and I’m so glad her collection is now fully accessible to researchers.

References

  • Epstein, Ed. Race, Real Estate, and Education: The University of Pennsylvania’s Interventions in West Philadelphia, 1960-1980. Diss. University of Pennsylvania, 2020.
  • Goldfarb, Lawrence, Peter Brown, and Thomas P. Gallagher. Seven Schools: A Story of Community Action for Better Education. The Young Great Society Building Foundation: Philadelphia, 1972.
  • Materials relating to the Mantua-Powelton Mini-School and “school street concept,” Folders 9-13, Box 2, Merle Easton Architectural Collection, Ms2021-028, Special Collections and University Archives, Virginia Tech, Blacksburg, Va.
  • “School in the Streets” in Progressive Architecture. New York: Reinhold, October 1970. Print.
  • Torre, Susana (ed.). Women in American Architecture: A Historic and Contemporary Perspective : A Publication and Exhibition Organized by the Architectural League of New York through its Archive of Women in Architecture. Whitney Library of Design, New York, 1977.
  • Victor H. Wilburn and Associates, Progress Report to Wilmington Housing Authority, Folder 7, Box 2, Merle Easton Architectural Collection, Ms2021-028, Special Collections and University Archives, Virginia Tech, Blacksburg, Va.





Jade Snelling Architecture, International Archive of Women in Architecture (IAWA)

Thresholds: A Look at the Margaret Hayward Playground and Structuring Spaces for Play

Earlier posts exploring Beverly Willis’s work can be found here and here. As those posts dealt with a residential renovation and the adaptation of technology to large-scale housing developments, this post is concerned with urban design of public spaces.

Part of an axonometric drawing, Margaret S. Hayward Playground, San Francisco, Ca., c. 1981. From the Beverly Willis Architectural Collection, Ms1992-019, Special Collections, University Libraries, Virginia Polytechnic Institute and State University.

In 1978 Beverly Willis, noted architect, artist, and photographer, was commissioned to rehabilitate a public space and pre-existing playground that serves the Laguna and Golden Gate neighborhoods of San Francisco. Her charge was to design and construct a small recreation building on this site, a two-block plot that already housed tennis courts, play structures, and a small storehouse. As discussed in the posts mentioned above, Willis’s design philosophy is heavily influenced by symbolic imagery. Indeed, in her book Invisible Images, she discusses her fascination with the power of images at length: their capacity to generate ideas, to captivate us, to contextualize architecture and ultimately to connect humans to nature. But here she also took her primary audience into account, namely children, and thus considered how young people on the threshold of young adulthood might interpret spaces and images differently than their grown-up counterparts.

  • Exterior elevations, Margaret S. Hayward Playground, San Francisco, Ca., February 20, 1981.
  • Schematic plan, Margaret S. Hayward Playground, San Francisco, Ca., October 10, 1979.

When conceptualizing a small building for the park, she wanted to evoke and foster the idea of play, and to frame the building as an invitation to play. She designed what she characterized as a “toy” building, which served the dual purpose of sparking children’s imaginations and enabling other functions, i.e., serving as an administrator office, restroom, and a service kitchen for park events. It serves a host of functional needs while it also works with the idiosyncrasies of the site.

As Willis wanted the building to feel fully integrated with the rest of the block, the building’s segmented design allowed the small structure to sprawl and fan out, creating a pavilion that descended via concrete steps to the play pit. The way it’s structured gives it the slight feeling of a dais. She designed an asymmetrical wall at an angle from the building with a child-sized arch such that there would be some fluidity between the practical and playful elements of the park. No doubt, the building exploits an unusual, exploded structure (akin to something you’d see in an axonometric drawing) to maximize its magical, whimsical appeal.

I’ll leave you with Bev’s own words:

“I designed the building to be lower in height than the tallest play equipment—like a toy building. The structure fans out of its tight corner site, and diagonal walls shift through the structure, like the joints of the armadillo shell. The façade stops at a wide walkway, bordered by three tiered steps. Together, these elements create an illusion of a stage platform. On the right wing ‘stage’ wall, which extends past the building, I placed an arched opening that leads nowhere but beckons the young to pass through and explore. The painted arch opening and circular moon above are as magical as Alice’s looking glass, leading from everywhere to everywhere” (Willis 87).

References

  • Willis, Beverly. Invisible Images: The Silent Language of Architecture. National Building Museum, 1997.
  • “Margaret Hayward Park Playground Building.” Beverly Willis Archive, Beverly Willis Architecture Foundation, https://beverlywillis.com/architecture-project/0716/.
Jade Snelling Architecture, International Archive of Women in Architecture (IAWA), Women's History

Nature and Geometry: River Run and Beverly Willis’s Classicism With a Twist

As part of an ongoing effort to digitize records representing Beverly Willis’s significant works and projects, I’ve been highlighting some of her work in posts here. In November 2019 I wrote a post about her firm’s work in developing a program called “CARLA” or Computerized Approach to Residential Land Analysis and its use in a land development project (Pacific Point Condominiums). This week I’ll be looking at a smaller scale, but no less stunning, project: the River Run Residence. The house itself is beautiful, but I wanted to examine how it embodies Willis’s approach to design. When looking at a final product (a building facade, polished interiors) it can be easy to forget just how many choices went into creating something cohesive. Yet looking at design records can tease out some of the labor and give perspective on the process of designing and building that’s often obscured or mystified in the way we talk about and look at architecture. While this post won’t go deeply into the design process, it will touch on a few of the generative ideas and organizing principles behind the final building.

Section, River Run Residence, 1983. From the Beverly Willis Architectural Collection, Ms1992-019, Special Collections, University Libraries, Virginia Polytechnic Institute and State University.

The axis of Beverly Willis’s design philosophy hews to that line between formal and informal: the formal geometries of classicism and the informal rusticity of regionalism. Willis believes that at its core, design is about the investigation of the symbolic content of forms/shapes, and the manipulation of images (for more on this, see Invisible Images). When thinking about design, it can be a long and iterative process of drafting, layering, modeling – leaving aside sourcing materials and overseeing construction – this amounts to creating and blending images to form novel yet coherent aesthetics.

The Willis-designed Palladian villa cum rustic ranch in Napa Valley, called River Run, is emblematic of this mode of design thinking. The balance of the colonnaded portico, dramatic windows, grand approach mixed with the redwood shingle siding – classicism inflected by the vernacular – are all the more impressive given River Run’s relaxed atmosphere as a retreat. This is an interesting example of how works are often colored by different influences that are channeled through a designer. “While she abided by general principles of symmetry and proportion, the local shingle style — with its spreading roof, plentiful windows, and use of natural colors and regional materials — was also a powerful influence” (58-59). Willis seems to view it as a process of simplification – synthesis and streamlining. “Although the house is quite large, it displays a consistent economy of lines and means. It draws from the vocabulary of classicism, but there’s nothing complicated about it” (Willis qtd in Nelson 60). The nature and geometry mentioned in the title – and, indeed, Willis’s philosophy in general – refer to some of the central tenets of classicism and classical philosophy – that there are natural ideals that humans gravitate toward, that shapes and forms reveal a hidden geometry.

Further reading

  • Nelson, Christina. “Modern Retreats.” Home. 1986: 58-61.
  • Nelson, Christina. “Powder Room Poise.” Home. August 1986: 70-74.
  • Willis, Beverly. Invisible Images: The Silent Language of Architecture. National Building Museum, 1997.
Jade Snelling Architecture, International Archive of Women in Architecture (IAWA), Women's History

Introducing CARLA: Pioneering Technology in Urban Planning

The Beverly Willis Architectural Collection, open for research at Special Collections and University Archives, holds many treasures: sumptuous drawings, correspondence, and photographic materials documenting the work of one of America’s great twentieth century designers. One such project we’ll be highlighting here shows Willis and Associates, Inc.’s, (WAI’s) work on an early land analysis program called CARLA. CARLA, or Computerized Approach to Residential Land Analysis, was a program developed by the firm in the 1970s that was on the vanguard of employing computing applications in site development.

The programs aim was to reduce construction costs by instrumentalizing and automating much of the initial planning process and environmental impact research. To this end, the firm enlisted the skills of a young urban design grad student, Jochen Eigen, to study and model the architectural planning process. His work aggregated and analyzed data on the proposed project’s user needs and the site’s zoning and topography (via a client-submitted map), which was then correlated with an internally developed database that contained information on thousands of residential sites and floor layouts – planners would iterate through the process repeatedly to determine ideal land allocations for building.

CARLA001

At the time of CARLA’s advent, land analysis was a fairly lengthy ordeal. It would take companies 4-6 months using traditional methods before they would be able to properly estimate financial cost and environmental impact. Implementing and using this new tool reduced that timeline to about three weeks. The process would result in a site perspective, analysis of soil and natural drainage patterns, areas of a plot suitable for development and areas in need of cut and fill. The program allowed easy comparison of design solutions and their respective costs.

While CARLA was specifically geared toward site analysis, it is still ancestrally linked to modern computer aided design programs. Its primary function was to optimize land use by determining the best planning unit, its placement on a parcel, the cost of doing cut and fills, etc., and these are all necessary design considerations that are layered into modern CAD/BIM software (the BIM stands for Building Information Modeling). The program turned a time-consuming, bespoke research process into something comparatively data-driven and efficient, enabling Willis’s firm to maintain its competitive edge during the recession of the 1970s. At the time of its implementation, its aim was to get more contracts for lucrative housing developments, while it also addressed another fundamental need, namely, environmental considerations in urban design.

The first such development WAI used the software for were condominiums commissioned by the Alpha Land Company, to be located on a sloping 9-acre beachfront property. In her book Invisible Images, Willis writes about the beginning of her work on the Pacific Point Condominiums, and the inadequacy of available tools for assessing cost and estimating damage to existing ecosystems. Early iterations of mapping and topographical analysis programs were created by the government during World War II and later adapted for use by oil companies for industrial use; by 1971, the Kansas Geological Survey department at the University of Kansas had developed a mapping and contour program called SURFACE II. This program would form the backbone of Eigen’s/WAI’s land analysis software. Willis recalls,

With these tools I carefully planned stepped terraces on the bluff side of the site downward toward the ocean and designed a bridgelike entry to the three-story building’s mid-section. My design used diagonally placed interior walls that slice through the apartment facades, elongating one side like a fan. These subtle diagonal wall planes direct the eye to a breathtaking view of the Pacific Ocean.

PacPt_reduced

PacPt001
Top: presentation drawing for Pacific Point Condominiums; bottom: photograph of development, found in Invisible Images

The history of CARLA’s development is further documented here. Some of the firm’s internal documentation of the software’s development is available in the Beverly Willis Architectural Collection and will soon be digitized and made available online as part of the library’s new digital platform.

LM Rozema Architecture, Local/Regional History

The Life and Architecture of Smithey & Boynton

After several years, I recently finished processing the Smithey & Boynton, Architects & Engineers Records, Ms1992-027. Partner in the firm, Kenneth L. Motley purchased the firm in 1992 and donated their historical records in 1992 and 1994. About 30% of the collection was made available before I arrived at Virginia Tech in 2014, but the oversize, rolled architectural drawings and blueprints were not (although I must thank my predecessors for labeling and locating the rolls, which helped me significantly). Over the past four years, I arranged, described, and boxed up nearly 1,500 project drawings, totaling over 220 cubic feet and including over 920 boxes. (This isn’t even the largest collection we have in Special Collections!)

Louis Phillipe Smithey and Henry B. Boynton formed the Smithey & Boynton partnership in 1935. Smithey & Boynton built and renovated thousands of buildings throughout the state of Virginia. They designed Lane Stadium and several other buildings on the Virginia Tech campus, buildings for the Norfolk & Southern Railway (now Norfolk Southern), and the Lyric Theatre and Armory Building in Blacksburg. The firm became best known for building public schools, even using the same basic layout for numerous schools. They had nearly 150 school design commissions from 1945 through 1953 in at least 19 counties and 10 cities in Virginia.

Drawings of the Armory Building in Blacksburg, designed by Smithey & Boynton:

Armory Building
Armory Building

Louis Phillipe Smithey (1890-1966)

Smithey graduated from Randolph-Macon College in 1910, before attending both Virginia Polytechnic Institute and Massachusetts Institute of Technology. He was an engineer for Virginia Bridge & Iron Company from 1916 to 1920. He then opened his own practice, before partnering with Matthews H. Tardy, as Smithey & Tardy from 1922 through 1932. Smithey again had his own practice, occasionally working with Henry B. Boynton, before they partnered as Smithey & Boynton in 1935. Smithey was a registered architect in Virginia and West Virginia, a fellow of the American Institute of Architects (AIA), and served as president of the Virginia chapter of the AIA in 1940. He also served in the U.S. Army during World War I and World War II. Smithey married Dorothy Terrill in 1938, and they had one daughter.

Photos and drawings of the Lyric Theatre in Blacksburg, designed by the firm of Louis Phillipe Smithey:

Henry B. Boynton (1899-1991)

Boynton graduated from Virginia Polytechnic Institute in 1923, before taking classes at the University of Illinois (now the University of Illinois in Urbana-Champaign). He worked for Carneal & Johnston, Architects & Engineers, from 1924 to 1928. (We previously wrote about Carneal & Johnston on this blog in “A New Collection and a New Look at Virginia Tech’s Architectural Style.”) Boynton joined Smithey’s practice in 1929, becoming a partner in Smithey & Boynton in 1935. He was a registered architect in Virginia, West Virginia, North Carolina, and Pennsylvania; held several positions of the Virginia chapter of the AIA; and served as the Governor’s appointee to the State Registration Board for Architects, Professional Engineers, and Land Surveyors from 1962 to 1972. Boynton also served on the VPI Alumni Board of Directors from 1969 to 1979 and the VPI Education Foundation, Inc.’s board from 1978 to 1982. He also served in the Army Corps of Engineers during the World War II. (Special Collections also has the Henry B. Boynton Papers, Ms1992-002, which include some records from Smithey & Boynton.)

Drawings of the Norfolk & Southern Railway’s General Storehouse in Roanoke, designed by Smithey & Boynton:

Norolk & Southern’s General Storehouse in Roanoke
Norolk & Southern’s General Storehouse in Roanoke

For more, I recommend reading “Smithey and Boynton and the Designing of Virginias Modern Architecture” by Mike Walker, which is about Smithey & Boynton’s work and includes photographs of some of their buildings, primarily in Covington, Virginia.

Update, Jan. 12, 2021: An archived version of the page by Mike Walker is available from the Wayback Machine from August 15, 2019.

vtspecblogger Architecture, Architecture, History, International Archive of Women in Architecture (IAWA), Uncategorized, Women's History

Trajectories of an Architects Design Sensibilities: From Student to Practitioner

Model of architectural design project.
AustellungsbauVariabelTransportabel, Architectural model, 1962

The beginning of the fall semester and the nearly overnight return to a bustling and lively campus provides a good opportunity to reflect on the essential thing that we do, which is to educate. Student works are common discoveries in the collections that form the International Archive of Women in Architecture (IAWA) and can tell us either about an architects own practice or their methods of classroom instruction. This post will focus on the former, with an eye to the role that archival collections can play in examining design sensibilities within the context of a developing architectural practice.

Drawing showing elevation and site plan sketches.
Concept drawing, Bahamas Nursing School, c. 1985.

One of the most profound ways to understand the progression of the aesthetic sensibilities of a creative professional is to examine their works (including inspirational materials, writing, and sketches) across their career. Looking at materials that span yearsor even decadesoffers a glimpse into how their style evolved, was refined, stayed constant, or in some cases shifted radically. With architects it is possible to trace the development not only of their design considerations, but also the changes in drawing techniques, enhanced observational skills, and a deeper understanding of spaces. It is often possible to see how they refine and expand their understanding of the outer world, visual culture, and the impact of spaces on the people who inhabit them.

Photograph of architectural model.
AustellungsbauVariabelTransportabel, Architectural model, 1962

The Exhibition HallVariableTransportable project was completed by Dorothee Stelzer King while she was an architecture student at the Hochschule fur Bildende Kunste in Berlin, Germany. Completed the same year that she received her degree, the project was based on a first-year design exercise involving the enlargement of a simple shape to create a complex design without adding extra material to the final structure.

Document outlining requirements and development of the project.
Description and requirements of the award-winning portable exhibition hall project.



Drawing showing interlocking shapes.
Concept drawing showing how a basic triangle is repeated and extended to create interlocking stars and circular forms that in turn interlock to create flexible, modular shapes.



Elevations, site plans, and details.
Elevations, site plans, and detail drawings for AustellungsbauVariabelTransportabel.

Ms2013-023, Dorothee Stelzer King, Folder 3Ms2013-023, Dorothee Stelzer King, Folder 3

The Dorothee Stelzer King collection also contains works that the architect completed at various points during her professional career, allowing researchers to study the progression of her designs over time. The series of concept drawings and plans for the Bahamas Nursing School in Nassau, Bahamas, shows Kings attention to understanding how educational spaces and their inhabitants interact. While the drawings show a move away from the more experimental design work seen in Exhibition HallVariableTransportable, they showcase a greater understanding of the practical nature of educational facilities and the importance of proper acoustics, seating, structural elements, and paths of movement through interior spaces.

Concept sketch for the Bahamas Nursing School, c. 1985



Site plan drawing.
Location plan, Bahamas Nursing School, April 16, 1985.



Construction photos.
Construction photographs showing exterior and interior spaces, including structural elements, of the Bahamas Nursing School project.

Ms2013_023_B001_F020toF024_002_BahamasNursing_Scrap_120Ms2013_023_B001_F020toF024_002_BahamasNursing_Scrap_118

Many other student and professional design projects and records can be accessed in the Special Collections Reading Room at Virginia Tech. The finding aid for the Dorothee Stelzer King Architectural Collection can be viewed online at Virginia Heritage. The collection is currently being digitized with funding from the Council on Library and Information Resources (CLIR) and will be available in full through the Virginia Tech digital library.

Anthony Wright de Hernandez Architecture, Just for Fun, Pop Culture, Science and Engineering

R. Buckminster Fuller

R. Buckminster Fuller. This name is probably familiar to most people in the United States. It conjures images of futuristic domed cities of the type typical to a mid-20th century vision of the future.

Cover of “Three Structures by Buckminster Fuller in the garden of the Museum of Modern Art, New York.”
Interior page of “Three Structures by Buckminster Fuller” depicting various aspects of his unique design elements.
Interior page from “Three Structures by Buckminster Fuller”

Richard Buckminster Fuller, also called Bucky, was a celebrity. He was an engineer, an architect, a veteran, an environmentalist, a philosopher, and a poet. He was a celebrity because of these things rather than in spite of them. He was born July 12, 1895 in Milton, Massachusetts. He went to Harvard University for two years but did not finish. He later went to the United States Naval Academy (1917). He was an officer in the United States Navy during World War I.

For me, Fuller is a legendary figure. I grew up with cultural references to “bucky” balls, images of domed cities in speculative fiction, and knowing conceptually about the structure of fullerenes. So, when I was wandering through the archives looking for something to post about this week, I was excited to see a box labeled “R. Buckminster Fuller Collection 1949-1978” (Ms1975-007). Opening it up was like opening a present.

Our collection includes one folder of correspondence from and to Fuller, three folders containing copies of things Fuller wrote, six folders of things written about Fuller, and two oversized folders containing some rather large items within those categories. Looking through the materials, they aren’t like what most people expect to find in an archives. They aren’t handwritten. They aren’t really old. They aren’t deteriorating. They’re just extremely fascinating.

The letters are from November 1953 – December 1962. Most are from Fuller’s time working on his business Geodesics, Inc. They are typed. They are unsigned. Yet, for a fan of his work, they are exhilarating to read. The first one I laid eyes on was written while Fuller was with the Department of Architecture at the University of Minnesota. As if these being Fuller’s own words wasn’t enough, a connection to Minnesota biases me in favor of something from the start.

In the letter, Fuller is telling Tyler Rogers of Owens-Corning Fiberglas Co. about the challenges and modifications of his designs that have been necessary because of a lack of the necessary facilities to safely employ fiberglas in their construction. The letter is a finely crafted plea for assistance from this fiberglas manufacturer, and, according to a note added at the end, the plea was successful leading Owens-Corning to supply all the fiberglas used in the project to construct Fuller’s dome.

Take a look. Maybe you’ll find it as fascinating as I do:

Fuller Letter 1Fuller Letter 2Fuller Letter 3

Digging further into the materials, even just glancing, I learned much more about this mythic figure from my childhood. Had he been alive today, I am confident Fuller would have been viewed as an activist. His engineering ideas were rooted in his conception of the need for humanity to work together to support itself. He felt that domes could solve world housing problems. He also felt that industrialization had led the world to war and that as long as income inequality was creating “energy slaves” we would inevitably progress into further wars. Dipping into our small collection yields evidence of these views quite quickly.

Fuller graphics 1.jpg
An illustration created by Fuller in 1927.

The above illustration hints at Fuller’s environmentalism and highlights his concern for housing the population of the Earth. It reads:

26% of Earth’s surface is dry land
85% of all Earth’s dry land is here shown
86% of all dry land shown is above equator
The whole of the human family could stand on Bermuda
All crowded into England they would have 750 sq feet each
“United we stand, divided we fall” is correct mentaly and spiritualy but falacious physicaly or materialy
2,000,000,000 new homes will be required in next 80 years

An example of his analysis of the world’s energy economy and its effect on the incidence of world conflict appears on the same folded sheet:

Fuller graphics 2.jpg

This graphic is from 1952 and is titled “The Twentieth Century.” His analysis reads:

World Industrialization: Its rate of attainment as an industrially objective advantage to individuals. i.e. When 100 inanimate energy slaves* are in continual active service per each and every family existing in governing economy and those energy slaves are primarily focused upon regeneratively advancing standards of living and in articulating amplifying degrees of intellectual and physical freedoms until critical point is reached majority of world men are “have nots” and are incitable to socialism by revolution against the seemingly ever more unduly privileged minority after 1972 majority are “haves”.
* One energy slave equals each unit of “one trillion foot pound equivalents per annum” consumed annually by respective economies from both import and domestic sources, computed at 100% of potential content

Overall, it’s an interesting plot. His analysis, while raising the specter of Communism as villain (typical of the early 1950s), shows global instability and a trend toward possible conflict through 1972. That tipping point is supposedly when most people in the world will go from being “have nots” to being “haves”. His predictions may or may not have been accurate (I’ll leave the correlative analysis up to you) but they certainly are interesting.

The last thing I’ll share is a portion of something I found somewhat interesting from among Fuller’s writings. Most of his writings in our collection are reprints of articles he had published. From a publishing standpoint, I find them interesting because of how they are printed. They are self-contained. In the case of the one I will share, an entire page describing articles in the publication is present but the only one that is printed with full clarity is the one by Fuller – the others have been “blurred” via the addition of slight pixilation of the ink in the printing process. I have yet to actually read this article, so I won’t go into depth. I also won’t share the entire thing here because I really don’t want to make the publication if came from mad at me. Also, just to be clear, I’m reading it for the article (I mean, really, that’s all that’s even here!).

Cover of a reprint booklet containing articles in Playboy and Think.
Description page from Playboy including the article description for Fuller’s article.
The first page of Fuller’s Playboy article.

This is just a hint of what’s in our R. Buckminster Fuller Collection (Ms1975-007). I plan to delve into it more myself to satisfy my curiosity about this fascinating man. Please stop by and do the same! And, if you want even more Buckminster Fuller content, Fuller donated his full archive to Standord University in 1999 where it is available as the R. Buckminster Fuller Collection.





jojacks2 Architecture, Faculty, Just for Fun, Uncategorized

Season’s Greetings from the Elarths and Friends

If your bloggers mailbox is an accurate barometer of popular culture, it seems the days of the holiday greeting card are steadily waning. With social media and email keeping us in constant contact with even the most distant acquaintances, many no longer feel the need to buy a card, write a brief note in it, and post it in the mail. To be sure, there are still those among us who send dozens of cards a year, but as a whole, we seem to be sending fewer cards. There was a time, though, in the not-so-distant past, when the holiday greeting card was an annual rite for many.

Unless they include lengthy personal messages, greeting cards are generally of little research value in a manuscript collection. The addresses on the envelopes can help in establishing a persons whereabouts at a particular time or in simply confirming that two people were acquainted, but for the most part, greeting cards are of little interest to researchers. An exception is when a greeting card includes personal information on the senders activities or when the card is handcrafted. In the manuscript collections of Herschel and Wilhelmina Elarth (Ms1969-004 and Ms1984-182), a number of handcrafted cards from professional artists can be found. If, like me, youre seeing a dearth of greeting cards in your mailbox, you may enjoy a look at a few of these unique cards.

But first, a bit of background on the couple in whose collections these cards are found:

Born in Rochester, New York, Wilhelmina van Ingen (1905-1969) was the daughter of Hendrik van Ingen, a well-known architect, and the granddaughter of Henry van Ingen, a painter of the Hudson River School (and perhaps the subject of a future blog post). After graduating from Vassar in 1926, Wilhelmina earned a masters degree in art history and classical archaeology from Radcliffe College. She later earned her doctoral degree at Radcliffe and taught art history at Wheaton College.

In 1942, Wilhelmina married Herschel Elarth (1907-1988), a professor of architecture at the University of Oklahoma. The couple moved to Canada in 1947, and both taught at the University of Manitoba. In 1954, Herschel accepted a position at Virginia Tech, and the Elarths moved to Blacksburg. While Herschel taught, Wilhelmina remained active with the American Association of University Women, the Blacksburg Regional Art Association, and the Associated Endowment Fund of the American School of Classical Studies.

Elarth001 The Professors Elarth

With their backgrounds in art, it’s of little surprise that the Elarths would have created their own cards, rather than purchasing them at a store:

Elarth005Elarth008

Even before they were married, Wilhelmina and Herschel sent personally crafted Christmas cards to friends and family. In the examples above, we can see Wilhelmina drawing on her background in classical studies for her 1932 card, while Herschels 1928 card displays his interest in architecture and statuary.

After their marriage, the Elarths continued to make and send their own cards:

Elarth006

Elarth007

The Elarths 1946 card (top) featured a woodblock print of an imposing gothic cathedral, while their 1954 card (bottom), a simple pen-and-ink sketch sent during their first Christmas in Blacksburg, reflected an appreciation for the natural beauty of their newfound home.

Their mutual interest in art led the Elarths to maintain a wide circle of friends in the art world, and they regularly traded holiday greetings with a number of their artistic friends. Many of these cards reflect the style and development of the individual artist.

Elarth009

Elarth010

Elarth011

Among the Elarths longtime friends were Richard and Peggy Bowman, whom they likely met while Richard Bowman was teaching at the University of Manitoba. An abstract painter, Bowman is credited with being among the first artists to use fluorescent paint in fine art. Among the cards sent by the Bowmans are two woodblock prints and an original abstract painting. As the Herschel Elarth collection contains other examples of Peggy Bowmans poetry, we can assume that she provided the brief poems in the two cards above. The painting at bottom, meanwhile, illustrates Richard Bowmans use of fluorescent paints.

Elarth012

Herschel Elarth likely met painter and muralist Eugene Kingman through the Joslyn Art Museum (Omaha, Nebraska), of which Kingman served as director and Elarth helped design. For many years, Kingman annually sent the Elarths a card bearing a woodblock print he’d made of a rural Nebraska scene, like this one from 1946.

Elarth013Elarth014Elarth015

Painter and printmaker William Ashby Bill McCloy (1913-2000) and his wife Patricia (Patty) also remembered the Elarths at the end of each year. The couple incorporated Bill McCloys work into limited-print cards, including those above: an untitled, undated print; The Greeting, (#17 of 65 limited prints), 1961; and an untitled 1958 print (#48 of 100 printed). (“Pax vobiscum nunc” translates from the Latin as “peace to you, now.”)

Canadian painter Takao Tak Tanabe (1926- ) was also likely an acquaintance of the Elarths from their time in Manitoba, Tanabe having been a student at the Winnipeg School of Art from 1946 to 1949. Tanabe sent the Elarths a number of beautiful cards through the years. Though he later became known for his paintings of British Columbia landscapes, the work displayed in his cards from the 1950s is much more abstract.

Elarth016

Takao Tanabes 1951 card opens to reveal an abstract rendition of New York City skyscrapers. At the time, Tanabe was studying at the Brooklyn Museum School of Art.

Elarth017

An abstract Christmas tree is featured in this undated card from Tanabe.

Elarth018

This undated card from Tanabe included an original work entitled “Mother and Child” on a canvas panel.

Elarth002Elarth003

One of the most unusual cards received by the Elarths is this selection from architect Caleb Hornbostel and family. In it, the architect plays with the card form by using it to provide recipients with instructions on building a model of a home he had designed.

Both Elarth collections contain much more than greeting cards. The Herschel Gustave Anderson Elarth Papers contain his artwork, materials relating to his teaching career, several of his more significant architectural projects, and his experiences in the 826th Engineer Aviation Battalion during World War II. You can view the collections finding aid here. The Wilhelmina van Ingen Elarth Papers, meanwhile, contain her extensive diaries (including those maintained while traveling in Europe), a substantial postcard collection, artwork of her father and grandfather, and a few pieces of ancient Aegean and pre-Columbian artifacts. More information may be found here, in the collections finding aid.

vtspecblogger Architecture, Interior Decoration, International Archive of Women in Architecture (IAWA), Uncategorized

The Role of Design in Cultivating and Enhancing Spiritual Connection

In the arts, one may find peace and contentment, for we may use our ability to transform our inner energy in a satisfying manner.
Melita Rodeck, AIA

Elevation drawing
Melita Rodeck, Consolata Missions Seminary, 1959.

Architect Melita Rodeck established the Regina Institute of Sacred Art in the late 1950sshortly after forming her own architectural firmwith the purpose of bringing together design professions to help establish a set of standards for the quality of sacred art. A large part of the organizational mission involved educat[ing] parishioners about the psychological need and emotional impact of good design. The institute also helped parishes to realize the significance of these ideas by participating in their efforts to redesign and redecorate religious spaces. (IAWA newsletter, no. 8, Fall 1996)

Ms1992_028_F002_001_HolyComfort_Dr_001
Melita Rodeck’s proposed sanctuary design for the Holy Comforter Church includes clean lines and minimal forms for the space and the furnishings that are both beautiful and functional.

Perhaps more significantly, one can look at Rodecks work with religious architectural spaces within the context of a much longer history dealing with what sacred art, architecture, and design should be expected to accomplish. Of particular relevance is the history of Catholic artistic engagement, with its strong implications that a sense of sacred beauty was essential to the message of eternal life and divine bliss. (Saward, John. “The Poverty of the Church and the Beauty of the Liturgy.” The Institute for Sacred Architecture 31 (Spring 2017).) This same notion is supported in the work of the Second Vatican Council, which dealt at length with religious art in the 1963 Sacrosanctum Concilium. Among the many doctrinal concepts outlined in this document were notions such as of their nature the arts are directed toward expressing in some way the infinite beauty of God in works made by human hands. The document further directed that such arts should seek for noble beauty rather than sumptuous display. (“Chapter VII: Sacred Art and Sacred Furnishings.” In Sacrosanctum Concilium. Second Vatican Council, 1963.)

Church
Melita Rodeck, Church Interior, Conceptual sketch

The Sacrosanctum Concilium further specifies that art can and should be reflective of the times and acknowledges that all manners of artistic styles have been embraced throughout the history of the Catholic church. This bears heavily on Rodecks approach to architectural design in these spaces, which is extensively modernist in its execution and carefully uses light, form, color, and scale to shape the experience within the space.

Ms1992_028_F002_018_ArchbishopChapel_Dr_001

This reflects a modernist sensibility of human-space interactions, moving away from a dependence on highly narrative interpretations of religious interiors in favor of evoking emotional responses to elements of the built environment. This approach also reflects a concern with religious harmony, and a tendency to encourage slightly decentralized expressions of devotion through the acts of meditation and contemplation, which are not necessarily rooted in any particular religious tradition. This is the emotional impact of good design that Rodeck spoke aboutit has the power to elicit a palpable and immersive connection, to invite parishioners to examine their own relationships with the mysterious, the sacred, the divine, and the spiritual.

Ms1992_028_F002_021_ArchbishopChapel_Dr_001

In The Role of Religious Art Over 50 Years: An Assessment, James Hadley concludesthat “the power of religious arts of the past 50 years has been their capacity to invite us to gaze more intently into the fragment, the incomplete reality we feel has seized us, and there begin to perceive the possibility of human psycho-spiritual and physical wholeness restored in the divine. (Hadley, James. Faith & Form: The Interfaith Journal on Religion, Art, and Architecture 50, no. 3 (September 1, 2017).) This sentiment is certainly reflected in Rodecks approach to creating spaces that are beautiful and minimal, that in their simplicity encourage meditation, connection, and reflection, and that arecapable of stirring profoundly complex experiences.



Materials from the Melita Rodeck Architectural Collection can be viewed in the Special Collections Reading Room at the Virginia Tech Libraries.
